BV series (rectangular) photoelectric sensor Key features: High sensing range Completely filled with resin Diffuse reflection proximity type detection (no transmitter or refector required) Multivoltage 20-253 VAC and TRIAC output with NO/NC selectable (AC types) Muntifunctional DECOUT© output and logic connection possibilities (DC types) SERIES BV series DESCRIPTION Cubic miniaturized photoelectric sensor SUPPLY PROTECTION Transient, short circuit INDEX PROTECTION IP IP67 LED INDICATION Red (output energized) HOUSING MATERIAL ABS polyetilene (cable exit) SENSITIVITY Adjustable SUPPLY VOLTAGE 20 – 253 VAC DIFFUSED Yes RETRO-REFLECTIVE No POLARISED RETRO No THROUGH-BEAM No SENSING DISTANCE (MM) 200 PNP No NPN No NO Yes NC Yes CONNECTOR Cable DIMENSIONS (MM) (H) 16 x (W) 37 x (D) 64/70
200mm NO/NC 20-253VAC DIFF PHOTO
Photoelectric sensors
ElectroMechanica
BV4/00-0C
