25kVAR 690V 3PH CAPACITOR 275.186-405600

690V three phase capacitors MKPg-275 three-phase power capacitors, dry self-healing dielectric, gas filled (N2) protecting windings from environmental influences extending life expectancy, permitting mounting in any position. table RATED VOLTAGE 690…760V, 50 Hz KVAR AT 690V 25 KVAR AT 760V 30 CN UF 3 x 56 DUTY Continuous (life expectancy 150000 h) DESCRIPTION 3 phase capacitor DISCHARGE RESISTORS Requires seperate discharge resistors TEMPERATURE CATEGORY 60 -40°C +60°C (Max: 24 hr average 50°C annual ave 40°C) DIMENSIONS (MM) 230 DIMENSIONS (MM) 116 STANDARD IEC/EN 60831, VDE 0560-46/47, CSA C22.2 190-M1985, UL 810, GOST 1282-88
