Fandis FLL series panel lamps During maintenance and inspection on switchboards it is essential for operators to have a good level of lighting in order to clearly see components within the panel. The use of LEDs provides effective illumination capacity within electrical cabinets at significantly low consumption. The slimline design makes the lamp ideal for applications in tight spaces providing greater installation versatility and guarantee of safety. Features: Lamp rotates to six different positions on base (max. to 40°) 120° radius with delayed auto off with no detected presence Magnetic fastening for simple positioning on metallic surfaces (with optional magnet set) Switching is via a mounted switch or version with a PIR sensor which detects motion within Termination is via push-in cage clamp terminals on both sides with an incorporated release button SERIES FLL series POWER (W) 5 DESCRIPTION LED panel lamp with push button switch OPERATING VOLTAGE 110/230 VAC OPERATING TEMPERATURE -30 to 60°C LIFETIME 160.000h at 25°C LED 290 Lm, 120°, daylight, colour temperature 6500K INFRATED SENSOR No, push button switch DIMENSIONS (MM) (H) 32 x (W) 356 x (D) 46
FLL-300565U-S
