Industrial switched sockets(interlocked) SCAME, ADVANCE 2 Series, interlocked socket outlets have smooth and well-connected surfaces, with no sharp edge or lines, included the hand grip, which ensure top safety and ergonomic use as well as easy cleaning, being installed in environments that particularly need such requirement. Advance 2 series industrial switch sockets(with incorporated 6 way distribution board) Surface mounting DIN rail facility for 6 x modular devices – MCB , earth leakage, contactors Features: Screwless plate Wide room for cabling Grip can be locked Plate with overprinted window Improved mechanical interlocking system. Threaded cable inlet with possible in-out device on the bottom Very few elements to be assembled for easy and quick installing and maintaining operations. SERIES ADVANCE 2 AMPERAGE 63A INSULATED VOLTAGE 690 VAC OPERATING TEMPERATURE -25 – +40°C (max operating temperature +60°C) GLOW WIRE TEST 650/850°C MATERIAL Engineering plastic (halogen free) NUMBER OF POLES 2P+E IMPACT RESISTANCE IK07 (500g with a striking energy of 2J) PIN CONFIGURATION 3pin INDEX PROTECTION IP IP67 DESCRIPTION Surface switch socket outlet MECHANICAL INTERLOCKED Only operates with plug inserted, plug only removable with switch off DIMENSIONS (MM) (H)303 x (W)136 x (D)166-207
63A 2P+E IP67 SURF SW/SOCKET + DB
