AH500 series Programmable Logic Controllers The new generation AH Series PLC provides automation solutions for high-level applications. The combination of modularised hardware structure, advanced functions and highly integrated software provide system solutions for advanced process control. In addition to various function blocks, excellent price/performance and an abundant selection of extension modules, the AH PLC also provides exceptional system expand ability, greatly reducing system cost for a broad range of applications. Key features: Utilizes a dual-core multi-tasking processor Excellent program execution speed: 0.3ms / 1k steps Enhanced flexibility: Max. 100 meters between 2 local extension racks Hot-swapping function keeps system running for improved maintainability CPU built-in with fully isolated RS232/422/485, Mini-USB, Ethernet, SD Card 1.0 Highly integrated software ISPSoft: graphical interface with 5 programming languages MaxI. I/O points: DIO: Max. 4.352 points AIO: Max. 544 channels RIO: Max. 125.440 digital points / 3.920 analog channels Program capacity: Max. 256K steps / Data register 64K words EN series CPU modules MODBUS RTU/ASCII 2048 timers and counters WEB/E-mail/IP Filter function Built-in Ethernet communication port NTP network time correction function Built-in SD card slot, Mini-USB programming port With built-in EtherNet communication port 100Mbps Built-in RS232/422/485 multi-modes communication port x 2 No battery required RTC function (max. 30 days after power off) Program execution speed: LD instruction @ 0.02¼ / 1K steps @ 0.3ms DESCRIPTION EN series CPU module LOCAL INPUT/OUTPUT (POINTS) 1280 PROGRAM CAPACITY (STEPS) 64K DATA REGISTER (K WORDS) D48/ L 48/ B1024 FUNCTION BLOCKS 256 EXTENSION BACKPLANE 1
AHCPU510-EN
