QM series cubic sensor Key features: Selectable LO/DO output state Complete protection against electrical damages Retro-reflective (polarised) used together with a reflector Available with cable and M8 plug exit or with M8-M12 pig-tail Completely filled with resin (except background suppression models) 2 kHz switching frequency, background suppression with mechanical adjustment Cubic miniaturized photoelectric high-performance sensors with long sensing distance SERIES QM series DESCRIPTION Cubic miniaturized photoelectric sensor SUPPLY PROTECTION Polarity reversal, impulse overvoltage, short circuit INDEX PROTECTION IP IP67 LED INDICATION Yellow (output status) / green (supply present) HOUSING MATERIAL PA66 SENSITIVITY Adjustable SUPPLY VOLTAGE 10 – 30 VDC DIFFUSED No RETRO-REFLECTIVE No POLARISED RETRO Yes THROUGH-BEAM No SENSING DISTANCE (MM) 5 meter PNP No NPN Yes NO Yes NC Yes CONNECTOR M8 plug (4 pin) DIMENSONS (MM) (H)12.8 x (W)21 x (D)31.2
QMRN/0N-0F
