Surge protection devices For the protection of low voltage equipment against transient voltage and current surges mainly from atmospheric origin (lightning) and transient produced by switching characteristics such as in switching of distribution networks, transformers, motors, etc. Features: Comply with the IEC 61643-11 Replaceable plug-in protection modules with visual fault indication Clamps voltage to less than 1500V as per SANS 10142-1:2008 table L1 Type 1 combined lightning current and surge arrester with integrated backup fuse Prewired spark-gap-based type 1 and 2 combined lightning current and surge arrester SERIES DEHNventil DESCRIPTION Combined lighting and surge protection device with integrated fuse TYPE Class 1 (10/350 ¼) L-N (LIMP) 35 kA MAXIMUM VOLTS L-N (Uc) 760 V VOLTAGE PROTECTION (Up) ‚¬° 4kV NUMBER OF POLES 1 CONFIGURATION Phase WIDTH IN 18 (MM) 3
TYPE1 35KA DEHNBLOC 1PH 760V SPD
Surge protection devices
ElectroMechanica
961176
