Surge protection devices for photovoltaic (PV) installations PSC PV is a combined device for discharging lightning currents (Type 1 / Class I) and protecting against induced transient overvoltages (Type 2 / Class II) for Photovoltaic installations, in accordance with EN 50539-11. DIN rail plug-in format. Protection for combiner boxes in areas with greater exposure to the atmosphere Exclusive device for photovoltaic systems according to EN 50539-11 No back-up fuse required due to dynamic thermal disconnect system – capacity of 10kA (Iscpv) SERIES PSC PV series (10/350 ¼) L-N (LIMP) 5kA (8/20 ¼) L-N (IMAX) 40kA MAXIMUM VOLTS L-N (Uc) 1060 V VOLTAGE PROTECTION (Up) ≤ 4.0 kV NUMBER OF POLES 3 CONFIGURATION L+/PE/L- WIDTH IN 18 (MM) 3 SIGNALLING Remote indication/monitoring of devices
PSC3-5/1000 PVIR
