Voltage Monitor The Electro 11 pin plug-in range of control and timing devices are to be installed into a standard 11 pin base making installation easy and convenient. The V1C is a precise UNDER / OVER voltage monitoring relay. The unit can be ordered in many AC / DC voltage ranges, making it ideal for many voltage monitoring applications. The set point and hysteresis can be adjusted with separate potentiometers. The unit also incorporates a latch facility to prevent undetected failures. Features: Output 10A SPDT relay Latch facility incorporated Measures separate voltage input Monitoring relay for voltage control Power supply ON and Relay ON LEOs Potentiometer adjustable voltage limits Potentiometer adjustable hysteresis limits Rear DIPswitch selection for 10sec start-up delay Rear DIPswitch selection of UNDER / OVER voltage DESCRIPTION Voltage monitor CONTACT 10A SPDT FUNCTION Over or under STANDARD MEASURING RANGES 4, 40, 400VAC/DC HYSTERESIS 5-50% RATED VOLTAGE 250V MECHANICAL LIFE 10×106 cycles PROTECTION INDEX IP IP 20 OPERATING TEMPERATURE -10 to + 50°C STORAGE TEMPERATURE -50 to + 85°C DIMENSIONS (MM) (H) 92 x (W) 36 x (D) 64
V1C230A400MV
